630-69 EM

Filters Sort results
Reset Apply
Product
SKU
Price
FEM000002



This is a single band fluorescence bandpass filter that has been optimized for use in a variety of fluorescence instruments. All our filters are thin-film, hard-coated filters for exceptional transmission performance and durability.

Product Specifications:

Optical Specification
Passband WL Range [nm]: 595 - 664
Passband Level [%, average]: 90
Blocking Band WL Range(s) [nm]: Band 1 Band 2
515 - 582 685 - 800
Blocking Level [OD, average]: 5
AOI Range [degrees]: 0 - 5
Cone Half Angle [degrees]: 7
Physical Specification
Ring Outer Diameter [mm]: 25 +0/-0.2
Ring Thickness [mm]: 3.5 /+- 0.1
Min. Clear Aperture [mm]: 21
Filter Thickness [mm]: 2 +/- 0.1
Surface Quality [S/D]: 80/50
Ring Label Details: IRIDIAN 630-69 Em FEM002(arrow)
